Pipe Plug, Inflatable, Multi-Flex®, 34" Dia
$1,510.00
2 In stock
SKU
113-034-
| Country of Origin | USA |
|---|---|
| Dia. Deflated | 5" (127mm) |
| Dia. Max | 34" (864mm) |
| Lngth Deflated | 81" (2058mm) |
| Length Overall Inflated, Est. | 60.7" (1543mm) |
| Length, Contact | 26" (660mm) |
| Length, Contact Max | 31.7" (804mm) |
| Length, Contact Min | 20.3" (517mm) |
| Material, Metal Components | Aluminum and Plated Carbon Steel |
| Material, Outer Ply | BallIstic Nylon |
| Package Dimensions | 36" X 8" X 8" |
| Pipeline Max Head | 4.5 psi (0.31 bar)/10' (3.2 m) |
| Port, Inflation | 2" MNPT to 1/2" QD Plug |
| Port, PSI Monitor | 1/4" QD Cplg |
| Infl. Max Pressure | 9 psi (0.62 bar) |
| Shipping Wt. | 15 Lb (6.80 Kg) |
| Temperature Max. Service F | 200 F (93.33 C) |
| Sage Subcategory Number | W113 |
Pipe Plug, Inflatable, Multi-Flex®, 34" Dia
| Country of Origin | USA |
|---|---|
| Dia. Deflated | 5" (127mm) |
| Dia. Max | 34" (864mm) |
| Lngth Deflated | 81" (2058mm) |
| Length Overall Inflated, Est. | 60.7" (1543mm) |
| Length, Contact | 26" (660mm) |
| Length, Contact Max | 31.7" (804mm) |
| Length, Contact Min | 20.3" (517mm) |
| Material, Metal Components | Aluminum and Plated Carbon Steel |
| Material, Outer Ply | BallIstic Nylon |
| Package Dimensions | 36" X 8" X 8" |
| Pipeline Max Head | 4.5 psi (0.31 bar)/10' (3.2 m) |
| Port, Inflation | 2" MNPT to 1/2" QD Plug |
| Port, PSI Monitor | 1/4" QD Cplg |
| Infl. Max Pressure | 9 psi (0.62 bar) |
| Shipping Wt. | 15 Lb (6.80 Kg) |
| Temperature Max. Service F | 200 F (93.33 C) |
| Sage Subcategory Number | W113 |
