Pipe Plug, Pipe Protector, Bell or Spigot, 140-0 Series
Pipe Plug, Pipe Protector, Bell, 140 Series
| Pipe Size, Nominal | Pipe Type | Pipe End | Shipping Wt. | Item Number | Price | Qty | Action |
|---|---|---|---|---|---|---|---|
| 60" (1524mm) | Vylon & Pro 21 Pipe | Bell | 65 Lb (29.48 Kg) | 140-060-9B |
$812.00
|
|
|
| 60" (1524mm) | Concrete Pipe | Bell | 65 Lb (29.48 Kg) | 140-060-3B |
$735.00
|
|
|
| 60" (1524mm) | Polyethylene Pipe | Bell | 65 Lb (29.48 Kg) | 140-060-2B |
$735.00
|
|
|
| 60" (1524mm) | Ductile Iron & C-900 Pipe | Bell | 65 Lb (29.48 Kg) | 140-060-1B |
$812.00
|
|
|
| 54" (1372mm) | Vylon & Pro 21 Pipe | Bell | 57 Lb (25.86 Kg) | 140-054-9B |
$733.00
|
|
|
| 54" (1372mm) | Concrete Pipe | Bell | 57 Lb (25.85 Kg) | 140-054-3B |
$680.00
|
|
|
| 54" (1372mm) | Polyethylene Pipe | Bell | 57 Lb (25.86 Kg) | 140-054-2B |
$680.00
|
|
|
| 54" (1372mm) | Ductile Iron & C-900 Pipe | Bell | 57 Lb (25.86 Kg) | 140-054-1B |
$733.00
|
|
|
| 48" (1219mm) | Vylon & Pro 21 Pipe | Bell | 39 Lb (17.69 Kg) | 140-048-9B |
$435.00
|
|
|
| 48" (1219mm) | Concrete Pipe | Bell | 39 Lb (17.69 Kg) | 140-048-3B |
$407.00
|
|
|
| 48" (1219mm) | Polyethylene Pipe | Bell | 39 Lb (17.69 Kg) | 140-048-2B |
$407.00
|
|
|
| 48" (1219.2mm) | Ductile Iron & C-900 Pipe | Bell | 39 Lb (17.69 Kg) | 140-048-1B |
$435.00
|
|
|
| 42" (1067mm) | Vylon & Pro 21 Pipe | Bell | 32 Lb (14.52 Kg) | 140-042-9B |
$362.00
|
|
|
| 42" (1067mm) | Concrete Pipe | Bell | 32 Lb (14.52 Kg) | 140-042-3B |
$333.00
|
|
|
| 42" (1067mm) | Polyethylene Pipe | Bell | 32 Lb (14.52 Kg) | 140-042-2B |
$333.00
|
|
|
| 42" (1067mm) | Ductile Iron & C-900 Pipe | Bell | 32 Lb (14.52 Kg) | 140-042-1B |
$362.00
|
|
|
| 36" (914mm) | Vylon & Pro 21 Pipe | Bell | 25 Lb (11.34 Kg) | 140-036-9B |
$278.00
|
|
|
| 36" (914mm) | Steel Gas | Bell | 25 Lb (11.34 Kg) | 140-036-8B |
$248.00
|
|
|
| 36" (914mm) | Concrete Pipe | Bell | 25 Lb (11.34 Kg) | 140-036-3B |
$248.00
|
|
|
| 36" (914mm) | Polyethylene Pipe | Bell | 25 Lb (11.34 Kg) | 140-036-2B |
$248.00
|
|
|
| 36" (914mm) | Ductile Iron & C-900 Pipe | Bell | 25 Lb (11.34 Kg) | 140-036-1B |
$278.00
|
|
|
| 33" (838mm) | Vylon & Pro 21 Pipe | Bell | 20 Lb (9.07 Kg) | 140-033-9B |
$267.00
|
|
|
| 30" (762mm) | Vylon & Pro 21 Pipe | Bell | 18 Lb (8.16 Kg) | 140-030-9B |
$252.00
|
|
|
| 30" (762mm) | Steel Gas | Bell | 18 Lb (8.16 Kg) | 140-030-8B |
$208.00
|
|
|
| 30" (762mm) | Ultra Rib | Bell | 18 Lb (8.16 Kg) | 140-030-7B |
$252.00
|
|
|
| 30" (762mm) | SDR 35 | Bell | 18 Lb (8.16 Kg) | 140-030-4B |
$252.00
|
|
|
| 30" (762mm) | Concrete Pipe | Bell | 18 Lb (8.16 Kg) | 140-030-3B |
$208.00
|
|
|
| 30" (762mm) | Polyethylene Pipe | Bell | 18 Lb (8.16 Kg) | 140-030-2B |
$208.00
|
|
|
| 30" (762mm) | Ductile Iron & C-900 Pipe | Bell | 18 Lb (8.16 Kg) | 140-030-1B |
$252.00
|
|
|
| 27" (686mm) | Vylon & Pro 21 Pipe | Bell | 13 Lb (5.90 Kg) | 140-027-9B |
$210.00
|
|
|
| 27" (686mm) | Ultra Rib | Bell | 13 Lb (5.90 Kg) | 140-027-7B |
$210.00
|
|
|
| 27" (686mm) | SDR 35 | Bell | 13 Lb (5.90 Kg) | 140-027-4B |
$210.00
|
|
|
| 27" (686mm) | Concrete Pipe | Bell | 13 Lb (5.90 Kg) | 140-027-3B |
$170.00
|
|
|
| 24" (610mm) | Vylon & Pro 21 Pipe | Bell | 9 Lb (4.08 Kg) | 140-024-9B |
$170.00
|
|
|
| 24" (610mm) | Steel Gas | Bell | 9 Lb (4.08 Kg) | 140-024-8B |
$132.00
|
|
|
| 24" (610mm) | Ultra Rib | Bell | 9 Lb (4.08 Kg) | 140-024-7B |
$170.00
|
|
|
| 24" (610mm) | SDR 26 | Bell | 9 Lb (4.08 Kg) | 140-024-5B |
$137.00
|
|
|
| 24" (610mm) | SDR 35 | Bell | 9 Lb (4.08 Kg) | 140-024-4B |
$137.00
|
|
|
| 24" (610mm) | Concrete Pipe | Bell | 9 Lb (4.08 Kg) | 140-024-3B |
$132.00
|
|
|
| 24" (610mm) | Polyethylene Pipe | Bell | 9 Lb (4.08 Kg) | 140-024-2B |
$132.00
|
|
|
| 24" (610mm) | Ductile Iron & C-900 Pipe | Bell | 9 Lb (4.08 Kg) | 140-024-1B |
$170.00
|
|
|
| 21" (533mm) | Vylon & Pro 21 Pipe | Bell | 8 Lb (3.63 Kg) | 140-021-9B |
$158.00
|
|
|
| 21" (533mm) | Ultra Rib | Bell | 8 Lb (3.63 Kg) | 140-021-7B |
$158.00
|
|
|
| 21" (533mm) | SDR 26 | Bell | 8 Lb (3.63 Kg) | 140-021-5B |
$127.00
|
|
|
| 21" (533mm) | SDR 35 | Bell | 8 Lb (3.63 Kg) | 140-021-4B |
$127.00
|
|
|
| 20" (508mm) | Ductile Iron & C-900 Pipe | Bell | 7 Lb (3.18 Kg) | 140-020-1B |
$152.00
|
|
|
| 18" (457mm) | Steel Gas | Bell | 7 Lb (3.18 Kg) | 140-018-8B |
$108.00
|
|
|
| 18" (457mm) | Ultra Rib | Bell | 7 Lb (3.18 Kg) | 140-018-7B |
$132.00
|
|
|
| 18" (457mm) | SDR 26 | Bell | 7 Lb (3.18 Kg) | 140-018-5B |
$108.00
|
|
|
| 18" (457mm) | SDR 35 | Bell | 7 Lb (3.18 Kg) | 140-018-4B |
$108.00
|
|
|
| 18" (457mm) | Concrete Pipe | Bell | 7 Lb (3.18 Kg) | 140-018-3B |
$108.00
|
|
|
| 18" (457mm) | Polyethylene Pipe | Bell | 7 Lb (3.18 Kg) | 140-018-2B |
$108.00
|
|
|
| 18" (457mm) | Ductile Iron & C-900 Pipe | Bell | 7 Lb (3.18 Kg) | 140-018-1B |
$132.00
|
|
|
| 16" (406mm) | Ductile Iron & C-900 Pipe | Bell | 7 Lb (3.18 Kg) | 140-016-1B |
$115.00
|
|
|
| 15" (381mm) | Steel Gas | Bell | 6 Lb (2.72 Kg) | 140-015-8B |
$98.30
|
|
|
| 15 " (381mm) | Ultra Rib | Bell | 6 Lb (2.72 Kg) | 140-015-7B |
$112.00
|
|
|
| 15" (381mm) | SDR 26 | Bell | 6 Lb (2.72 Kg) | 140-015-5B |
$98.30
|
|
|
| 15" (381mm) | SDR 35 | Bell | 6 Lb (2.72 Kg) | 140-015-4B |
$98.30
|
|
|
| 15" (381mm) | Concrete Pipe | Bell | 6 Lb (2.72 Kg) | 140-015-3B |
$98.30
|
|
|
| 15" (381mm) | Polyethylene Pipe | Bell | 6 Lb (2.72 Kg) | 140-015-2B |
$98.30
|
|
|
| 14" (356mm) | Ductile Iron & C-900 Pipe | Bell | 4 Lb (1.81 Kg) | 140-014-1B |
$108.00
|
|
|
| 12" (305mm) | Steel Gas | Bell | 4 Lb (1.81 Kg) | 140-012-8B |
$83.30
|
|
|
| 12" (305mm) | Ultra Rib | Bell | 4 Lb (1.81 Kg) | 140-012-7B |
$103.00
|
|
|
| 12" (305mm) | SDR 21 & 26 (cl 160) | Bell | 4 Lb (1.81 Kg) | 140-012-6B |
$83.30
|
|
|
| 12" (305mm) | SDR 26 | Bell | 4 Lb (1.81 Kg) | 140-012-5B |
$83.30
|
|
|
| 12" (305mm) | SDR 35 | Bell | 4 Lb (1.81 Kg) | 140-012-4B |
$83.30
|
|
|
| 12" (305mm) | Concrete Pipe | Bell | 4 Lb (1.81 Kg) | 140-012-3B |
$83.30
|
|
|
| 12" (305mm) | Polyethylene Pipe | Bell | 4 Lb (1.81 Kg) | 140-012-2B |
$83.30
|
|
|
| 12" (305mm) | Ductile Iron & C-900 Pipe | Bell | 4 Lb (1.81 Kg) | 140-012-1B |
$103.00
|
|
|
| 10" (254mm) | Ultra Rib | Bell | 4 Lb (1.81 Kg) | 140-010-7B |
$78.30
|
|
|
| 10 " (254mm) | SDR 21 & 26 (cl 160) | Bell | 4 Lb (1.81 Kg) | 140-010-6B |
$75.00
|
|
|
| 10" (254mm) | SDR 26 | Bell | 4 Lb (1.81 Kg) | 140-010-5B |
$75.00
|
|
|
| 10" (254mm) | SDR 35 | Bell | 4 Lb (1.81 Kg) | 140-010-4B |
$75.00
|
|
|
| 10" (254mm) | Concrete Pipe | Bell | 4 Lb (1.81 Kg) | 140-010-3B |
$75.00
|
|
|
| 10" (254mm) | Polyethylene Pipe | Bell | 4 Lb (1.81 Kg) | 140-010-2B |
$75.00
|
|
|
| 10" (254mm) | Ductile Iron & C-900 Pipe | Bell | 4 Lb (1.81 Kg) | 140-010-1B |
$78.30
|
|
|
| 8" (203mm) | Steel Gas | Bell | 3 Lb (1.36 Kg) | 140-008-8B |
$40.00
|
|
|
| 8" (203mm) | Ultra Rib | Bell | 3 Lb (1.36 Kg) | 140-008-7B |
$45.00
|
|
|
| 8" (203mm) | SDR 21 & 26 (cl 160) | Bell | 3 Lb (1.36 Kg) | 140-008-6B |
$40.00
|
|
|
| 8" (203mm) | SDR 26 | Bell | 3 Lb (1.36 Kg) | 140-008-5B |
$40.00
|
|
|
| 8" (203mm) | SDR 35 | Bell | 3 Lb (1.36 Kg) | 140-008-4B |
$40.00
|
|
|
| 8" (203mm) | Concrete Pipe | Bell | 3 Lb (1.36 Kg) | 140-008-3B |
$40.00
|
|
|
| 8" (203mm) | Polyethylene Pipe | Bell | 3 Lb (1.36 Kg) | 140-008-2B |
$40.00
|
|
|
| 8" (203mm) | Ductile Iron & C-900 Pipe | Bell | 3 Lb (1.36 Kg) | 140-008-1B |
$45.00
|
|
|
| 6" (152mm) | Steel Gas | Bell | 3 Lb (1.36 Kg) | 140-006-8B |
$35.00
|
|
|
| 6" (152mm) | SDR 21 & 26 (cl 160) | Bell | 3 Lb (1.36 Kg) | 140-006-6B |
$35.00
|
|
|
| 6" (152mm) | SDR 26 | Bell | 3 Lb (1.36 Kg) | 140-006-5B |
$35.00
|
|
|
| 6" (152mm) | SDR 35 | Bell | 3 Lb (1.36 Kg) | 140-006-4B |
$35.00
|
|
|
| 6" (152mm) | Concrete Pipe | Bell | 3 Lb (1.36 Kg) | 140-006-3B |
$35.00
|
|
|
| 6" (152mm) | Polyethylene Pipe | Bell | 3 Lb (1.36 Kg) | 140-006-2B |
$35.00
|
|
|
| 6" (152mm) | Ductile Iron & C-900 Pipe | Bell | 3 Lb (1.36 Kg) | 140-006-1B |
$38.30
|
|
Pipe Plug, Pipe Protector, Spigot, 140 Series
| Pipe Size, Nominal | Diameter | Pipe Type | Pipe End | Shipping Wt. | Item Number | Price | Qty | Action |
|---|---|---|---|---|---|---|---|---|
| 60" (1524mm) | Vylon & Pro 21 Pipe | Spigot | 65 Lb (29.48 Kg) | 140-060-9S |
$812.00
|
|
||
| 60" (1524mm) | 60" (1524mm) | Concrete Pipe | Spigot | 65 Lb (29.48 Kg) | 140-060-3S |
$735.00
|
|
|
| 60" (1524mm) | Polyethylene Pipe | Spigot | 65 Lb (29.48 Kg) | 140-060-2S |
$735.00
|
|
||
| 60" (1524mm) | 61.81" (1570mm) | Ductile Iron & C-900 Pipe | Spigot | 65 Lb (29.48 Kg) | 140-060-1S |
$812.00
|
|
|
| 54" (1372mm) | 53.5" (1359mm) | Vylon & Pro 21 Pipe | Spigot | 57 Lb (25.86 Kg) | 140-054-9S |
$733.00
|
|
|
| 54" (1372mm) | 54" (1372mm) | Concrete Pipe | Spigot | 57 Lb (25.86 Kg) | 140-054-3S |
$680.00
|
|
|
| 54" (1372mm) | 40.46" (1028mm) | Polyethylene Pipe | Spigot | 57 Lb (25.86 Kg) | 140-054-2S |
$680.00
|
|
|
| 54" (1372mm) | 56.17" (1427mm) | Ductile Iron & C-900 Pipe | Spigot | 57 Lb (25.86 Kg) | 140-054-1S |
$733.00
|
|
|
| 48" (1219mm) | 47.5"(1207mm) | Vylon & Pro 21 Pipe | Spigot | 39 Lb (17.69 Kg) | 140-048-9S |
$435.00
|
|
|
| 48" (1219mm) | 48" (1219mm) | Concrete Pipe | Spigot | 39 Lb (17.69 Kg) | 140-048-3S |
$407.00
|
|
|
| 48" (1219mm) | 41.44" (1052mm) | Polyethylene Pipe | Spigot | 39 Lb (17.69 Kg) | 140-048-2S |
$407.00
|
|
|
| 48" (1219mm) | 49.53" (1258mm) | Ductile Iron & C-900 Pipe | Spigot | 39 Lb (14.52 Kg) | 140-048-1S |
$435.00
|
|
|
| 42" (1067mm) | 41.5" (1054mm) | Vylon & Pro 21 Pipe | Spigot | 32 Lb (14.52 Kg) | 140-042-9S |
$362.00
|
|
|
| 42" (1067mm) | 42" (1067mm) | Concrete Pipe | Spigot | 32 Lb (14.52 Kg) | 140-042-3S |
$333.00
|
|
|
| 42" (1067mm) | 36.26" (921mm) | Polyethylene Pipe | Spigot | 32 Lb (14.52 Kg) | 140-042-2S |
$333.00
|
|
|
| 42" (1067mm) | 43.31" (1100mm) | Ductile Iron & C-900 Pipe | Spigot | 32 Lb (14.52 Kg) | 140-042-1S |
$362.00
|
|
|
| 36" (914mm) | 35.5" (902mm) | Vylon & Pro 21 Pipe | Spigot | 25 Lb (11.34 Kg) | 140-036-9S |
$278.00
|
|
|
| 36" (914mm) | Steel Gas | Spigot | 25 Lb (11.34 Kg) | 140-036-8S |
$248.00
|
|
||
| 36" (914mm) | 36" (914mm) | Concrete Pipe | Spigot | 25 Lb (11.34 Kg) | 140-036-3S |
$248.00
|
|
|
| 36" (914mm) | 31.08" (789mm) | Polyethylene Pipe | Spigot | 25 Lb (11.34 Kg) | 140-036-2S |
$248.00
|
|
|
| 36" (914mm) | 37.19" (945mm) | Ductile Iron & C-900 Pipe | Spigot | 25 Lb (11.34 Kg) | 140-036-1S |
$278.00
|
|
|
| 33" (838mm) | Vylon & Pro 21 Pipe | Spigot | 20 Lb (9.07 Kg) | 140-033-9S |
$267.00
|
|
||
| 30" (762mm) | 29.5" (749mm) | Vylon & Pro 21 Pipe | Spigot | 18 Lb (8.16 Kg) | 140-030-9S |
$252.00
|
|
|
| 30" (762mm) | Steel Gas | Spigot | 18 Lb (8.16 Kg) | 140-030-8S |
$208.00
|
|
||
| 30" (762mm) | 29.5" (749mm) | Ultra Rib | Spigot | 3 Lb (1.36 Kg) | 140-030-7S |
$252.00
|
|
|
| 30" (762mm) | 28.15" (715mm) | SDR 35 | Spigot | 18 Lb (8.16 Kg) | 140-030-4S |
$252.00
|
|
|
| 30" (762mm) | Concrete Pipe | Spigot | 18 Lb (8.16 Kg) | 140-030-3S |
$208.00
|
|
||
| 30" (762mm) | 25.990" (658mm) | Polyethylene Pipe | Spigot | 18 Lb (8.16 Kg) | 140-030-2S |
$208.00
|
|
|
| 30" (762mm) | 30.97" (787mm) | Ductile Iron & C-900 Pipe | Spigot | 18 Lb (8.16 Kg) | 140-030-1S |
$252.00
|
|
|
| 27" (686mm) | 26.5" (673mm) | Vylon & Pro 21 Pipe | Spigot | 13 Lb (5.90 Kg) | 140-027-9S |
$210.00
|
|
|
| 27" (686mm) | 26.5" (673mm) | Ultra Rib | Spigot | 13 Lb (5.90 Kg) | 140-027-7S |
$210.00
|
|
|
| 27" (686mm) | SDR 35 | Spigot | 13 Lb (5.90 Kg) | 140-027-4S |
$210.00
|
|
||
| 27" (686mm) | 27" (686mm) | Concrete Pipe | Spigot | 13 Lb (5.90 Kg) | 140-027-3S |
$170.00
|
|
|
| 24" (610mm) | 23.5" (597mm) | Vylon & Pro 21 Pipe | Spigot | 9 Lb (4.08 Kg) | 140-024-9S |
$170.00
|
|
|
| 24" (610mm) | 22.624" (575mm) | Steel Gas | Spigot | 9 Lb (4.08 Kg) | 140-024-8S |
$132.00
|
|
|
| 24" (610mm) | 23.5" (597mm) | Ultra Rib | Spigot | 9 Lb (4.08 Kg) | 140-024-7S |
$170.00
|
|
|
| 24" (610mm) | 22.15" (563mm) | SDR 26 | Spigot | 9 Lb (4.08 Kg) | 140-024-5S |
$137.00
|
|
|
| 24" (610mm) | 22.52" (572mm) | SDR 35 | Spigot | 9 Lb (4.08 Kg) | 140-024-4S |
$137.00
|
|
|
| 24" (610mm) | 24" (610mm) | Concrete Pipe | Spigot | 9 Lb (4.08 Kg) | 140-024-3S |
$132.00
|
|
|
| 24" (610mm) | 16.73" (425mm) | Polyethylene Pipe | Spigot | 9 Lb (4.08 Kg) | 140-024-2S |
$132.00
|
|
|
| 24" (610mm) | 24.85" (631mm) | Ductile Iron & C-900 Pipe | Spigot | 9 Lb (4.08 Kg) | 140-024-1S |
$170.00
|
|
|
| 21" (533mm) | Vylon & Pro 21 Pipe | Spigot | 8 Lb (3.63 Kg) | 140-021-9S |
$0.00
|
|
||
| 21" (533mm) | 20.75" (527mm) | Ultra Rib | Spigot | 8 Lb (3.63 Kg) | 140-021-7S |
$158.00
|
|
|
| 21" (533mm) | SDR 26 | Spigot | 8 Lb (3.63 Kg) | 140-021-5S |
$127.00
|
|
