Pipe Plug, Mech, Hp Test, For 18" Sch-Std, 2" Npt Bypass
More Information
| By-Pass Flow Through Cap Type |
Not Included |
| By-Pass Size |
2" MNPT |
| Country of Origin |
USA |
| Depth, Full Installation |
12.60" (320.1mm) |
| Functional ID Range |
17.17"-17.63" (436.1mm-447.8mm) |
| Hex Nut Wrench Size |
1-5/8" |
| Length, Gripper |
4.74" (120.4mm) |
| Length, Seal to Gripper |
7.92" (201.2mm) |
| Lngth, Overall |
17.94" (455.7mm) |
| Material, Body |
NPT Plain Steel & Far End Support with Integral Vents - Ductile Iron |
| Material, Hardware |
Hex Nuts (1 Per Shaft) Black Oil Finish/Cast Ductile Iron Positioning/top Washers with Tabs |
| Material, Seal |
Urethane |
| Nominal Pipe |
18" (457.2mm) |
| Pipe Schedule |
STD |
| Plug OD |
17.07" (433.6mm) |
| Press., Max Test, PSI |
3000 psi (206.8 bar) |
| Sage Subcategory Number |
W147 |
| Shaft Quantity |
10 |
| Shaft/Port I.D. |
1.69" (42.9mm) |
| Shipping Wt. |
430 Lb (195 Kg) |
| Total Clearance From Min. I.D. |
0.1" (2.5mm) |
| Type |
6 |
