Pipe Plug, MF, Oil Resist, ByPass 115 Series
| Image | Dia. Max | Dia. Deflated | By-Pass | Pipe Plug Inflation Max Press. | Pipeline Pressure Max Head | Port, Inflation | Length Deflated | Shipping Wt. | Item Number | Price | Qty | Action |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
72" (1829mm) | 10" (254mm) | 3/4 F | 4 psi (0.28 bar) | 2 psi (0.14 bar)/4.6' (1.41 m) | 3/8" F - 1/2" QD Plug | 191" (4851mm) | 130 Lb (58.97 Kg) | 115-072- |
$9,300.00
|
||
|
66" (1676mm) | 10" (254mm) | 3/4 F | 4 psi (0.28 bar) | 2 psi (0.14 bar)/4.6' (1.41 m) | 3/8" F - 1/2" QD Plug | 176" (4470mm) | 106 Lbs (48.08 Kg) | 115-066- |
$8,500.00
|
||
|
60" (1524mm) | 10" (254mm) | 3/4 F | 4.5 psi (0.31 bar) | 2.25 psi (0.16 bar)/5.19' (1.58 m) | 3/8" F - 1/2" QD Plug | 160" (4064mm) | 91 Lb (41.28 Kg) | 115-060- |
$8,000.00
|
||
|
54" (1372mm) | 9" (229mm) | 3/4 F | 5 psi (0.34 bar) | 2.5 psi (0.17 bar)/5.8' (1.76 m) | 3/8" F - 1/2" QD Plug | 145" (3683mm) | 81 Lb (36.74 Kg) | 115-054- |
$6,800.00
|
||
|
48" (1219mm) | 9" (229mm) | 3/4 F | 6.5 psi (0.45 bar) | 3.25 psi (0.22 bar)/7.5' (2.28 m) | 3/8" F - 1/2" QD Plug | 129" (3277mm) | 70 Lb (31.75 Kg) | 115-048- |
$4,090.00
|
||
|
42" (1067mm) | 8" (203mm) | 3/4 F | 9 psi (0.62 bar) | 4.5 psi (031 bar)/10.4 (3.16 m) | 3/8" F - 1/2" QD Plug | 114" (2896mm) | 58 Lb (26.31 Kg) | 115-042- |
$3,570.00
|
||
|
36" (914mm) | 7" (178mm) | 3/4 F | 9 psi (0.62 bar) | 4.5 psi (031 bar)/10.4 (3.16 m) | 3/8" F - 1/2" QD Plug | 97" (2464mm) | 50 Lb (22.68 Kg) | 115-036- |
$2,980.00
|
||
|
33" (838mm) | 7" (178mm) | 3/4 F | 9 psi (0.62 bar) | 4.5 psi (031 bar)/10.4 (3.16 m) | 3/8" F - 1/2" QD Plug | 90" (2286mm) | 47 Lb (21.32 Kg) | 115-033- |
$2,470.00
|
||
|
30" (762mm) | 6" (152mm) | 3/4 F | 9 psi (0.62 bar) | 4.5 psi (031 bar)/10.4 (3.16 m) | 3/8" F - 1/2" QD Plug | 82" (2083mm) | 42 Lb (19.05 Kg) | 115-030- |
$2,100.00
|
||
|
|
28" (711mm) | 6" (152mm) | 3/4" F | 9 psi (0.62 bar) | 4.5 psi (0.31 bar)/10.4' (3.16 m) | 3/8" F - 1/2" QD Plug | 76" (1930mm) | 36 Lb (16.33 Kg) | 115-028- |
$1,810.00
|
||
|
24" (610mm) | 6" (152mm) | 3/4 F | 10 psi (0.69 bar) | 5 psi (0.34 bar)/11.5' (3.52 m) | 3/8" F - 1/2" QD Plug | 66" (1676mm) | 34 Lb (15.42 Kg) | 115-024- |
$1,340.00
|
||
|
20" (508mm) | 6" (152mm) | 3/4 F | 20 psi (1.38 bar) | 10 psi (0.69 bar)/23.1' (7.03 m) | 3/8" F - 1/2" QD Plug | 56" (1422mm) | 31 Lbs (14.06 Kg) | 115-020- |
$1,210.00
|
||
|
18" (457mm) | 6" (152mm) | 3/4 F | 22 psi (1.52 bar) | 11 psi (0.76 bar)/25.4' (7.73 m) | 3/8" F - 1/2" QD Plug | 51" (1295mm) | 28 Lb (12.70 Kg) | 115-018- |
$1,100.00
|
||
|
16" (406mm) | 5.5" (140mm) | 3/4 F | 25 psi (1.72 bar) | 12.5 psi (0.86 bar)/28.8' (8.79 m) | 3/8" F - 1/2" QD Plug | 46" (1168mm) | 26 Lb (11.79 Kg) | 115-016- |
$910.00
|
||
|
15" (381mm) | 5.5" (140mm) | 3/4 F | 25 psi (1.72 bar) | 12.5 psi (0.86 bar)/28.8' (8.79 m) | 3/8" F - 1/2" QD Plug | 44" (1118mm) | 24 Lb (10.89 Kg) | 115-015- |
$853.00
|
||
|
12" (305mm) | 4.5" (114mm) | 3/8 F | 25 psi (1.72 bar) | 12.5 psi (0.86 bar)/28.8' (8.79 m) | 3/8" F - 1/4" QD Plug | 40" (1016mm) | 17 Lb (7.71 Kg) | 115-012- |
$756.00
|
||
|
10" (254mm) | 3.5" (89mm) | 1/8 F | 30 psi (2.07 bar) | 15 psi (1.03 bar)/34.6' (10.55 m) | 1/8" F - 1/4" QD Plug | 26" (660mm) | 13 Lb (5.90 Kg) | 115-010- |
$594.00
|
||
|
8" (203mm) | 3.5" (89mm) | 1/8 F | 30 psi (2.07 bar) | 15 psi (1.03 bar)/34.6' (10.55 m) | 1/8" F - 1/4" QD Plug | 21" (533mm) | 11 Lb (4.99 Kg) | 115-008- |
$529.00
|
||
|
6" (152mm) | 3" (76mm) | 1/8 F | 30 psi (2.07 bar) | 15 psi (1.03 bar)/34.6' (10.55 m) | 1/8" F - 1/4" QD Plug | 19" (483mm) | 10 Lb (4.54 Kg) | 115-006- |
$443.00
|
||
|
4" (102mm) | 2.5" (64mm) | 1/8 F | 30 psi (2.07 bar) | 15 psi (1.03 bar)/34.6' (10.55 m) | 1/8" F - 1/4" QD Plug | 16" (406mm) | 6 Lb (2.72 Kg) | 115-004- |
$410.00
|
||
|
3" (76mm) | 2.5" (64mm) | 1/8 F | 30 psi (2.07 bar) | 15 psi (1.03 bar)/34.6' (10.55 m) | 1/8" F - 1/4" QD Plug | 16" (406mm) | 6 Lb (2.72 Kg) | 115-003- |
$389.00
|
