Pipe Plug, Petestop®, Inflatable Flow Stop, 17.25" Dia
$10,800.00
| Country of Origin | USA |
|---|---|
| Dia. Deflated | 12.875" (327mm) |
| Dia. Hot Tap Hole, Min | 13" (330mm) |
| Dia. Max | 17.25" (438mm) |
| Flow Rate, Est. max | 8741GPM (33089L/M) |
| Length Deflated | 48.5" (1232mm) |
| Length, Cylinder Contact | 13.5" (343mm) |
| Length, Overall, Inflated, IN | 29.5" (749mm) |
| Material, Hardware | Aluminum and Plated Carbon Steel |
| Material, Outer Ply | Ballistic Nylon Reinforced Urethane |
| Package Dimensions | 60" X 14" X 14" |
| Port Location, Infl. | Flow anchor |
| Port, Inflation | 2" X 300 Lb ANSI |
| Pressure Pipeline Max Head | 153 ft (46.63 m) |
| Pressure, Inflation Max | 100 psi (6.90 bar) |
| Sage Subcategory Number | W1298 |
| Shipping Wt. | Call for Weight |
| Temperature Max. Service F | 225 F (107.22 C) |
